Silver Big Screen Access Control For AI Facial Recognition Time
Attendance System
Yecon Technology is the world's leading smart terminal and one-stop
solution provider in AI intelligent hardware industry, specialized
in face recognition time attendance, access control terminals, Body
temperature measuring and so on. more than 2,300 employees and 170
engineers including app solution development engineers, electronic
engineer, structural engineers, process engineers, they can provide
strong tech to support online management platform open to
customized SDK APK.
And Yecon own dust-free workshop for SMT and Assembly process, with
a very strict 7S standardized process management system, to ensure
all the products are in good condition. We’d like to share our face
recognition device to all the people to provide a touchless work
and life environment, that’s will be safety, efficiently and
environmentally friendly.
Basic Parameters
| Device shell | Aluminum alloy (IP67 design, can be used in outside) |
| Operating system | Android7.1 |
| CUP | RK3399 six-core high-performance CPU composed of four cores of A53
and two cores of A72 |
| Memory | Standard:RAM 2GB LPDDR3 Memory:16GB EMMC |
| Temperature measuring module brand | HIK vision from China. | Touch screen : | 10.1“ multipoint capacitive touch screen |
| measuring distance: | 0.3-2M |
| Temperature measuring resolution | 160*120 Faster speed,higher accuracy ,longer measurement Distance | Screen resolution: | 800*1280 |
| Interface | LAN | 10/100M self-adaptive |
| WLAN/WI-FI | 2.5/5GHz double-frequency WIFI 802.11 a/b/g/n |
| Bluetooth | V5.0(Standard) |
| Data interface | USB3.0*1 USB2.0*1 |
| Microphone | x1 |
| Sound | Speaker 1.5W*2 |
| Key | Reset, Recovery) |
| RS232 | RS232*1 |
| RS485 | RS485*1 |
| Wiegand interface | Support |
| GPIO interface | *2 (Alarm switch, door magnetic detection) |
| Power supply | 12V2A/POE power supply, support DC extension cord, 0.5 square line
≥100 m |
| Operating Environment | Operating temperature | 30℃ ~ 45℃ | ESD | ±4kV exposure, ±8kV air |
| Operating humidity | 20%-95% noncondensing | Lightning protection | Not support |
| Storage temperature | -30℃ ~ +80℃ | Surge | Support |
| Power consumption | Max <18w | Harmonic | Support |
| Protection grade | Whole set IP67 | Uninterrupted | 7*24 |
| function: |
| Single or multiple face recognition |
| Single or multiple temperature detection |
| employee or students time attendance |
| smart access control |
| card reader |
| software |
| standalone software in the device itself |
| support controlled by mobilephone or computer though simple scan
the QR code at LAN envirement |
| support powerful back-stage management by one-key installation on
computer at LAN envirement |
| support remote management if you like create your own cloud server
under our assist |
TR10D, is the new launched product in 2022, with 10.1-inch screen,
built-in temperture measuring module and Cutting-edge design it's
really a unique products with private mould in the market right
now, Let you have absolute pricing power!
Due to there have some different install ways, and use for
different scene, so we have corresponding configuration products,
like the wall-mounted, floor stand,Desktop, with hand
Disinfector,with printer, and so on. so could you please let's know
what kind of product do you want, and how many you'd like for the
order, so that we can send more details for you check.
we can support small quantity order, and also support OEM and ODM
base on MOQ1000, looking forward your further information, thanks!
