Body Temperature Detection AI Face Scan Face Recognition Door
Access System
2300 workers, 45000 ㎡ non-dust workshop, 18 years experience, ISO,
CE, FCC, Rohs certificated, located in Shenzhen China, this is how
we keep good quality and competitive prices for global valued
customers.
The all in one device is widely use in office, hospital, smart
building, super market, school, and so on, we have some videos for
you easy understand the operation of the products, please let me
know if you need it.
If the product meet your demand, please feel free to contact us.
We're sure your any inquiry or requirement will get prompt
attention.
| Device shell | Aluminum alloy |
| Operating system | Android7.1 |
| CUP | RK3399 six-core high-performance CPU composed of four cores of A53
and two cores of A72 |
| Memory | Standard:RAM 2GB LPDDR3 Memory:16GB EMMC |
| Temperature measuring module brand | HIKvision from China. | Touch screen : | 8“ multipoint capacitive touch screen |
| measuring distance: | 0.3-2M |
| Temperature measuring resolution | 160*120 Faster speed,higher accuracy ,longer measurement Distance | Screen resolution: | 800*1280 |
| Interface | LAN | 10/100M self-adaptive |
| WLAN/WI-FI | 2.5/5GHz double-frequency WIFI 802.11 a/b/g/n |
| Bluetooth | V5.0(Standard) |
| Data interface | USB3.0*1 USB2.0*1 |
| Microphone | x1 |
| Sound | Speaker 1.5W*2 |
| Key | Reset, Recovery) |
| RS232 | RS232*1 |
| RS485 | RS485*1 |
| Wiegand interface | Support |
| GPIO interface | *2 (Alarm switch, door magnetic detection) |
| Power supply | 12V2A/POE power supply, support DC extension cord, 0.5 square line
≥100 m |
| Operating Environment | Operating temperature | 30℃ ~ 45℃ | ESD | ±4kV exposure, ±8kV air |
| Operating humidity | 20%-95% noncondensing | Lightning protection | Not support |
| Storage temperature | -30℃ ~ +80℃ | Surge | Support |
| Power consumption | Max <18w | Harmonic | Support |
| Protection grade | Whole set IP67 | Uninterrupted | 7*24 |
Camera settings
[note]: camera settings are hidden by default. You need to click 15
times APP version to enter to Developer Mode. Process as: system
Settings > about Devices > APP version, quickly click 15
times, then return to Application settings page, you will see the
camera seetings.
[video stream angle]: 0, 90, 180, 270 degrees respectively.
Configure the rotation angle of the video.
[face detection angle]: 0, 90, 180, 270 degrees respectively.
Configure the rotation angle.
[video stream image]: Video flipping, similar to raising your right
hand. The left hand is displayed on the device. If the mirror image
is opposite, this function can be turned on
[face detection image]: face drawing box, similar to your face
moving right and drawing box moving left. If the drawing box is on
the contrary, this function can be turned on
[binocular camera]: Provide high precision detection.
