Wide Dynamic Face Recognition Card Reader 8" Time Attendance Access Control System Free SDK API

Application settings:

[Change administrator password]: Modify the password of the device about long pressing the upper right corner.

[Switch language]: Switch application language.

[Voice Prompt mode]: There are 3 modes: sound prompts, voice prompts, and custom voices. The sound prompts are just short sound effects. The voice prompts are short sentences. custom: According to the region habit, customers can configure the voice by themselves. The following will write how to add custom voices.

[LOGO]: Name the LOGO file with “logo.png”, and save it in the root directory of the USB flash drive. It is recommended that the height should not exceed 196px. Insert the U disk and click the slide button.

[Custom screen saver]: Name it “screenSaver.png” to store in root directory of the USB disk. It is recommended that 800*1280px or 1080*1920px size. insert U disk and slide button.

[Screen saver time(seconds)]: Idle time Screen saver access time

[Update application]: Rename the upgrade file to “update.apk”. store update.apk to the root directory of the U disk, and insert the U disk into the device. and click the file name in the device to start update.

Interface Parameters	Antiwithdrawal Key	Suppot
	Ethernet	100M
	232/dry contact	Support
	USB	1*USB
	RS485	Support
	Wiegand	Support
	GPIO	Support
	Relay	Support
	MICPH0NE	Support
Card-swiping Parameters (optional)	Protocol	Support IS0/IEC14443A,IS0/IEC14443B
	Frequency	13.56MHz
	Read Range	0-50mm
Other Parameters	Installation	Support wall-mounted, turnstile gate, floor stand, desk top
	Operating Voltage	12V/1.8A
	Operating Temperature	-10°C~60°C
	Protection Grade	IP67(don’t support temperature detection models)
	Standard Accessories	Manual, power adapter, screws
	Optional Accessories	Gate post,floor stand

Basic Parameters	Touch Screen	2. 5D Capacitive touch screen
	Screen Size	8”
	Screen Resolution	800 * 1280
	Operating System	Android 7.1
	CUP	Six-core, double Cortex-A72+4 Cortex-A53
	RAM	2G
	Memory	16G
	Camera	Infrared eyes, 200W wide dynamic range
	Camera Resolution	Medical grade infrared thermometric module, accuracy ±0.3℃
	WI-FI	Support
	Bluetooth	Optional
	Body Induction	Support
	Fill Light	white, red, green
	Dimensions	239*134*20. 6 mm
	Net Weight	1110g

=

2300 workers, 45000 ㎡ non-dust workshop, 18 years experience, ISO, CE, FCC, Rohs certificated, located in Shenzhen China, this is how we keep good quality and competitive prices for global valued customers.

The all in one device is widely use in office, hospital, smart building, super market, school, and so on, we have some videos for you easy understand the operation of the products, please let me know if you need it.

If the product meet your demand, please feel free to contact us. We're sure your any inquiry or requirement will get prompt attention.

 Yecon is a professional manufacturer which specialized in the research, development, production, sale and service of face recognition time attendance, access control terminals, handheld biometric, RFID terminal solutions such as time attendance, access control, door locks, readers and modules. With an industry-leading experienced R&D team and manufacturing head offices in Shenzhen, Yecon technology has introduced a series of advanced equipment including SMT, Reflow, X-RAY. In addition, we have obtained CE, ROHS, FCC certificates, ISO9001 is also included. Yecon products have served all over the world, and our overseas branches is under construction. We are constantly improving our technological capability, operational efficiency and product quality. Our most valuable assets are our corps of skilled and experienced professionals. We are proud to employ many leading technologists in China. Our vision is to become the world's leading supplier of intelligent products and solutions, Our mission is use artificial intelligence to solve business needs, our core values is Integrity, innovation, responsibility, professional, team and struggle. OEM ODM is also preferred by us. Whether selecting a current product from our catalog or seeking engineering assistance for your application, you can talk to our customer service center about your sourcing requirements. It is pleased and welcomed to get your inquires.
